SILICONI |ZINCOSIL 430 Cold galvanising gloss finish

Removes oxides after stainless steel welding.

Available in 2 kg and 10 kg jars in paste form

Pickling is the operation that removes all oxides after welding, by eliminating the surface layer depleted as a result of heat treatment.
It is the most important step in the treatment process.
It should be noted that a weld bead is a surface that has been heated and generally loses its stainless properties.
For these reasons, the pickling operation does not only mean cleaning the weld beads but primarily consists of restoring the characteristics of stainless steel.

How to use Picklinox paste?

Degrease the surface to be treated with the specific product CLEANOX.
Then apply a layer of paste.
Rinse with water after a variable period depending on the grade of stainless steel and the type of welding (up to 30 minutes).
Do not expose the product or the treated surface to sunlight or any atmospheric agent.

Special welding coolant is essential for optimizing and preserving the performance of your spot welder's cooling system, and is also suitable for other welding processes. Its unique formula, anti-corrosive and low-conductivity, reduces the effects of electrolysis. The special welding coolant prevents the build-up of deposits and blockage of the cooling circuit compared to a standard coolant.

Its advantages:

1) Its low conductivity limits the risk of electrolysis in the cooling circuit and prevents deposits responsible for blockages in the cooling circuit.
2) Anti-corrosive in contact with heavy metals.
3) Frost-resistant down to -20°C, for operation even in the most demanding conditions.
4) Its ready-to-use formula can be used pure without any dilution.

Available in two packaging sizes of 5 or 10 litres

ZINCONSIL 400 is to be used for cold galvanizing on all metallic materials with a high zinc content.
This aerosol product with a high zinc content is particularly suitable for touch-ups after welding, for restoration or galvanizing of metal sheets, for galvanizing and protecting metal parts outdoors, and for restoring the zinc surfaces of grilles, gates, sheets, tanks and metal structures.
The aerosol is fitted with a drip-free diffuser; its use does not cause stains.
ZINCONSIL 400 also provides good protection against corrosion caused by atmospheric agents such as salinity and humidity.

500 ml aerosol

PROPERTIES
High zinc content
Fast drying, drip-free
High covering power
Durable protection
High resistance to corrosion, atmospheric agents and oxidation
Paintable
Colour identical to galvanizing

INSTRUCTIONS FOR USE
Shake before use for one minute until the ball inside moves freely.
Even during application, shake the product regularly to keep it homogeneous. Clean and degrease the surfaces to be treated. Spray from a distance of approximately 25 cm.
After use, invert the aerosol and spray the product for a few seconds to prevent the valve from clogging.

Dry film thickness: 20 to 40 µm (cross-coat coverage)
Covering power: high
Coverage capacity: approx. 120 ml/m²
Drying time: 5 to 10 minutes. Fast drying, drip-free

This brush is used for applying stainless steel cleaning products.
Plastic handle, acid-resistant.

Two diameters available: 6 and 8 mm

Cleaning pad kit for Cleantech 200 Telwin
This item is used when cleaning with the CLEAN IT cleaner
These pads are suitable for cleaning large weld beads

This brush is used for applying stainless steel cleaning products.
Plastic handle, acid-resistant.

Brush width 30 mm
Handle length 30 cm

CERAM STAK is used to protect the torch from welding spatter.
Suitable for MIG/TIG torches, laser and plasma cutting, automatic welding machines.
Lubricant for high-temperature surfaces.

500 ml aerosol can

DESCRIPTION
CERAM STAK is an excellent anti-spatter product for protecting the torch tip from droplet adhesion. It lasts several hours (up to 8 hours) and has a superior anti-adhesive effect compared to standard silicone-free anti-spatter products, because it withstands high temperatures.
CERAM STAK is also an excellent lubricant. It deposits a thin dry film that improves action, prevents friction and reduces deformation. It can be used to lubricate work tables, furnaces, foundry slides, and whenever a high-temperature lubricant is needed.

INSTRUCTIONS FOR USE
Apply to the surface to be treated, which must first be thoroughly cleaned and degreased.
Shake the aerosol for at least one minute. During application, shake the aerosol regularly to keep the product homogeneous.
Spray the product from a distance of 15 cm to deposit a thin film.
After use, shake the aerosol for a few seconds to unblock the valve.
Shelf life is 2 years from the date of manufacture.

SPECIFICATIONS
Base: Microfine ceramic
Propellant: Denatured odourless hydrocarbon
Appearance: White dry film
Temperature resistance: 1500°C – at 200° the resins blend and become a nano-ceramic powder.
Drying time: 5 minutes
Contains no CFCs or silicone.

ALUSIL is a spray product containing a high level of aluminum. It is suitable for welding touch-ups and for protecting aluminum parts from oxidation.
It forms a film that restores and protects aluminum surfaces.
It can be painted over or left without a final protective coating.

400 ml aerosol

INSTRUCTIONS FOR USE
Clean and degrease the parts to be treated. Shake the aerosol vigorously until the ball moves, and during application, continue to shake the product occasionally to keep it homogeneous. Spray from a distance of 25 cm.
After use, invert the aerosol and spray the product for a few seconds to prevent valve blockage.

CHARACTERISTICS
Base: Pure aluminum paint
Propellant: Odorless denatured hydrocarbon
Coverage power: High
Dry film thickness: 15/20 microns
Drying: Fast
Temperature resistance: High
Color: Metallic
Specific gravity: 0.9 kg/lt
Dry residue: Approximately 30'

3 products for complementary use:

PENETRANT:
Red dye used to highlight small defects that may cause leaks.

DEVELOPER:
White powder product. It is used in conjunction with the PENETRANT and highlights small defects that may cause leaks.
Its white powder draws out by capillary action the red penetrant embedded in the crack from a thickness of 30 microns.
Easy to apply, non-destructive testing.

CLEANER:
Surface cleaner to be used before and after dye penetrant testing.
Penetrates into the smallest cracks and removes excess PENETRANT.

RIVELEX 200 is an aerosol product for detecting cracks or porosity caused by welding in all types of materials. Thanks to its composition, RIVELEX 200 can be applied very quickly, as it contains fast-evaporating solvents that leave a white powder on treated surfaces, enabling crack detection.
It can be used with red and fluorescent penetrants (PENTRIX 100).

400 ml aerosol

INSTRUCTIONS FOR USE
Shake the aerosol for at least one minute before use.
Spray RIVELEX 200 at a distance of approximately 20 to 30 cm onto the part that has been previously treated with a liquid penetrant.
Wait 10 to 20 minutes for the product to be fully effective.
Then inspect the treated materials.
This product causes no damage to treated materials.
The bases used comply with the regulations, ASME 2644 type II; MIL-I-25135 form D type II..

CHARACTERISTICS
Base: Mixture of solvents and white powders
Propellant: Denatured hydrocarbon, odorless
Appearance: White liquid
CFC-FREE

The Lincoln Freezcool special welding coolant is a ready-to-use heat transfer fluid. It contains an algaecide that limits fouling caused by algae growth in the cooling system.
Its thermal stability and dielectric properties make it a coolant particularly suited to high-technology circuits.

Fields of application:
Cooling of welding torches
Cooling of induction furnaces
Cooling of spot welding circuits, plasma torches

Non-volatile (no product loss), antifreeze protection down to -27°C - does not polarize, non-toxic and non-flammable, anti-corrosion and anti-algae.

Supplied in a 9.6 L container

CLINOX Green is a cleaner for stainless steel and chrome surfaces.
CLINOX Green is an innovative product as it contains biodegradable detergents free of hexane and chlorinated compounds, with high detergent power. Furthermore, its formula is highly concentrated in active ingredients, with a reduced propellant content.
It removes rings, grease, oils, and dirt, and leaves a protective film that reduces future scratches and protects machines from stains, dust, marks, and corrosion.
It does not scratch or stain. It contains no substances that could damage, stain, or harm treated surfaces.
CLINOX Green cleans stainless steel surfaces on industrial equipment, kitchens, refrigerators, doors, countertops. Biodegradable. Eco-compatible

500 ml aerosol

DIRECTIONS FOR USE
Shake the dispenser before use.
Spray the product onto a dry cloth and clean the surfaces

SPECIFICATIONS
Base: Biodegradable cleaner
Propellant: Mixture of denatured, odorless and non-toxic propellants
Appearance: White liquid
pH: 6 - 8
Keep away from heat sources and out of direct sunlight.
Store in a dry place at temperatures between +5°C and +35°C.
Shelf life: 12 months

PROTECT 700 is an anti-spatter liquid used to prevent the adhesion of slag or welding spatter.
This product contains no silicone and therefore allows subsequent surface treatments (painting, galvanizing, chromating).
PROTECT 700 can be used in an enclosed space as it is neither flammable nor toxic.
It can be diluted with water in a ratio of 1 to 5; for welding robots, it is recommended to dilute the product with water in a ratio of 1 to 1; for application with a pump, it is possible to use the product pure or diluted 1 to 1.

Base: Synthetic oil, silicone-free.
Appearance: Light yellow
Viscosity at 25°C: 30-100 cSt (Brookfield)
Temperature resistance: from -2°C to +200°C
Biodegradability: over 80%
Dilution: with water in all proportions
pH: 7 to 8
Non-flammable, non-toxic, odorless.

INSTRUCTIONS FOR USE
• Fill a sprayer:
• Spray at 20 cm from the part to be protected
• Deposits a thin, uniform film facilitating the rapid removal of welding spatter
• Remove with a degreaser or cleaner before galvanizing or painting the part(s) that have received SOUDURE ANTI GRATTONS

 It is also possible to apply this anti-spatter product with a brush on the surface to be treated.

Removes oxides after stainless steel welding.

Available in 2 kg and 10 kg tubs in gel form

Pickling is the operation that removes all oxides after welding, by removing the surface depleted as a result of heat treatment.
It is the most important step in the treatment process.
It must be taken into account that a weld bead is a surface that has been heated and generally loses its stainless properties.
For these reasons, the pickling operation does not simply mean cleaning the weld beads but primarily consists of restoring the stainless steel's characteristics.

How to use Picklinox paste?

Degrease the surface to be treated with the specific product CLEANOX.
Then apply a layer of paste.
Rinse with water after a variable time depending on the grade of stainless steel and the type of welding (up to 30 minutes).
Do not expose the product or the treated surface to sunlight or any atmospheric agent.

SUPER BALL is the best method for finding a gas leak on pressurized parts. Bubbles appear at the location of the leak. It can be used on all gases, even at low pressure (nitrogen, carbon dioxide, refrigeration systems).
Thanks to its formulation with specially selected components, it reveals micro-leaks on low surface tension surfaces

500 ml aerosol

INSTRUCTIONS FOR USE
Shake the aerosol well before use.
Spray the product from a distance of 10 cm;
For professional use only

CHARACTERISTICS
Base: Mixture of foaming components
Propellant: Denatured and odorless hydrocarbon
Appearance: White foamy liquid
Application temperature: -10°C to +130°C (approximately)
Biodegradability: Greater than 80%
Odor: None
CFC-FREE, non-toxic

Stainless steel weld cleaning liquid for wide or long weld beads
1 L container.
Applied with a suitable pad. Reference 981866
