SILICONI | PENTRIX 100 - Crack detector

The DETECT FUITES is a water-based product containing an antifreeze additive, anti-corrosion additives and surfactants that give it very high efficiency in immediately locating gas leaks on all circuits. It can be used with all types of gas (compressed air, hydrocarbons, CO2, nitrogen… except pressurised oxygen)
The DETECT FUITES works by forming air bubbles around the gas leak. The DETECT FUITES is frost-resistant and can be used down to -20°C.
The DETECT FUITES is over 80% biodegradable.
Safe to use on pneumatic circuits, fittings, valves, taps, safety valves or cylinders.

MAIN FEATURES
• Immediately visible detection
• Instant bubble or foam formation
• Neutral towards substrates
• Non-flammable
• Over 99% biodegradable
• Leaves no residue
• Contains anti-corrosion agents
• Formulated with an antifreeze agent -20°C
• Do not use on pressurised oxygen — use DETECTO FUITES Ref.: 005511
• Aerosol usable in all positions
FIELDS OF APPLICATION
• Suitable for detecting leaks of:
• Compressed air, CO², Nitrogen
• Butane, Propane
• Gas used in air conditioning systems
• Refrigerant gas
• Leak detection on: • Pipework, • Valves, • Fittings, • Gate valves, • Safety valves, • Gas cylinders

Net capacity 400 ml - 650 ml aerosol can.
Made in France.

SUPER BALL is the best method for finding a gas leak on pressurized parts. Bubbles appear at the location of the leak. It can be used on all gases, even at low pressure (nitrogen, carbon dioxide, refrigeration systems).
Thanks to its formulation with specially selected components, it reveals micro-leaks on low surface tension surfaces

500 ml aerosol

INSTRUCTIONS FOR USE
Shake the aerosol well before use.
Spray the product from a distance of 10 cm;
For professional use only

CHARACTERISTICS
Base: Mixture of foaming components
Propellant: Denatured and odorless hydrocarbon
Appearance: White foamy liquid
Application temperature: -10°C to +130°C (approximately)
Biodegradability: Greater than 80%
Odor: None
CFC-FREE, non-toxic

3 products for complementary use:

PENETRANT:
Red dye used to highlight small defects that may cause leaks.

DEVELOPER:
White powder product. It is used in conjunction with the PENETRANT and highlights small defects that may cause leaks.
Its white powder draws out by capillary action the red penetrant embedded in the crack from a thickness of 30 microns.
Easy to apply, non-destructive testing.

CLEANER:
Surface cleaner to be used before and after dye penetrant testing.
Penetrates into the smallest cracks and removes excess PENETRANT.

RIVELEX 200 is an aerosol product for detecting cracks or porosity caused by welding in all types of materials. Thanks to its composition, RIVELEX 200 can be applied very quickly, as it contains fast-evaporating solvents that leave a white powder on treated surfaces, enabling crack detection.
It can be used with red and fluorescent penetrants (PENTRIX 100).

400 ml aerosol

INSTRUCTIONS FOR USE
Shake the aerosol for at least one minute before use.
Spray RIVELEX 200 at a distance of approximately 20 to 30 cm onto the part that has been previously treated with a liquid penetrant.
Wait 10 to 20 minutes for the product to be fully effective.
Then inspect the treated materials.
This product causes no damage to treated materials.
The bases used comply with the regulations, ASME 2644 type II; MIL-I-25135 form D type II..

CHARACTERISTICS
Base: Mixture of solvents and white powders
Propellant: Denatured hydrocarbon, odorless
Appearance: White liquid
CFC-FREE
